Product Main Technical Parameters
| SPECIFICATIONS | Units | AMC500 | AMC650 | AMC800 |
| Table size | mm | φ500 | Φ650 | Φ800 |
| T-slot size | mm | 14H8 | 14H8 | 18H8 |
| Table center hole | mm | φ50H7 | φ50H8 | φ50H8 |
| Max.table load | kg | 350 | 850 | 1200 |
| X-axis travel | mm | 500 | 600 | 850 |
| Y-axis travel | mm | 600 | 650 | 850 |
| Z-axis travel | mm | 450 | 600 | 700 |
| A-axis rotation range | ° | ±120 | ±120 | ±120 |
| C-axis rotation range | ° | 360 | 360 | 360 |
| Distance from spindle nose to table surface | mm | 150-580 | 150-750 | 150-850 |
| Spindle taper | -- | HSK-A63 | HSK-A63 | HSK-A63 |
| Max.spindle speed | rpm | 18000 | 15000 | 15000 |
| Spindle motor power | kW | 22/33 | 25/37.5 | 25/37.5 |
| Max.torque of spindle | N.m | 61.3/90.7 | 91.7/37.5 | 91.7/137.7 |
| Tool magazine type | -- | Flat Chain Type | Flat Chain Type | Flat Chain Type |
| Tool magazine capacity | pcs | 32 | 40 | 40 |
| Max.diameter tool(full/Empty) | mm | Φ76/Φ125 | Φ76/Φ125 | Φ76/125 |
| Max.tool length | mm | 300 | 300 | 300 |
| Max.tool weight | kg | 8 | 8 | 8 |
| Tool change time(T-T) | S | 2~~4 | 2~~4 | 2~~4 |
| Rapid feed speed(X/Y/Z) | mm/min | 36000/36000/36000 | 36000/36000/36000 | 32000/32000/32000 |
| Cutting feed speed(X/Y/Z) | mm/min | 1-10000/1-10000/1-10000 | 1-10000/1-10000/1-10000 | 1-10000/1-10000/1-10000 |
| Positioning accuracy(X/Y/Z) | mm | 0.008 | 0.008 | 0.008 |
| Positioning accuracy(A/C) | mm | 5 | 5 | 5 |
| Repeat positioning accuracy(X/Y/Z) | kg | 0.005 | 0.005 | 0.005 |
| Repeat positioning accuracy(A/C) | mm | 4 | 4 | 4 |
| Machine weight | 11000 | 15000 | 18000 | |
| Machine overall size(L*W*H) | 5500*2350*3100 | 4600*3840*3300 | 5500*4000*3500 |
