Product Main Technical Parameters
| SPECIFICATIONS | Units | BMC650 |
| Table size | mm | φ650*540 |
| T-slot size | mm | 14 |
| Table center hole dia | mm | φ50 |
| Max.table load | kg | 300 |
| X-axis travel | mm | 650 |
| Y-axis travel | mm | 520 |
| Z-axis travel | mm | 475 |
| B-axis rotation range | ° | ±120 |
| C-axis rotation range | ° | 360 |
| Distance from spindle nose to table surface | mm | 150-625 |
| Spindle taper | -- | BBT40 |
| Max.spindle speed | rpm | 12000 |
| Spindle motor power | kW | 7.5 |
| Max.torque of spindle | N.m | 45 |
| Tool magazine type | -- | Arm type |
| Tool magazine capacity | pcs | 24 |
| Max.diameter tool(full/Empty) | mm | φ78/φ150 |
| Max.tool length | mm | 300 |
| Max.tool weight | kg | 8 |
| Tool change time(T-T) | s | 1.55 |
| Rapid feed speed(X/Y/Z) | mm/min | 42000/42000/42000 |
| Cutting feed speed(X/Y/Z) | mm/min | 1-10000/1-10000/1-10000 |
| Positioning accuracy(X/Y/Z) | mm | 0.005/300 JIS |
| Positioning accuracy(A/C) | " mm | 5 |
| Repeat positioning accuracy(X/Y/Z) | mm | 0.003 JIS |
| Repeat positioning acauracy(A/C) | " | 4 |
| Machine weight | kg | 8500 |
| Machine overall size(L*W*H) | mm | 3970*3210*2800 |
