Product Main Technical Parameters
Band Saw Machine Main Performance Characteristics：
1. High-capacity hand control by two-speed motor,
2. The European design hand saw has the advantage of double-speed selection,
3. The falling speed of saw bow is controlled by hydraulic cylinder,
4. It is equipped with a block feeder(with fixed sawing length).
5. Automatic feeding and clamping,
6. Metric and inch two kinds of feeding length can be selected,
7. 3m length feeding and back platform,
8. With manual defend net, can protect operators safety effectively,
9. Effective width of feeder stand:460mm,
10. Height of feeder stand:850mm,
11. Max. feeding(single):500mm.
Band Saw Machine Application：
For high precision metal cutting, is the ideal equipment for the industrial and mining enterprises and small workshops, use is very extensive.
Band Saw Machine Main Technical Parameters:
| Model | BS-460GB | ||
| Machining capacity | Round steel@90° | 330mm(13″) | |
| Square steel@90° | 460×250mm(18″×9.8″) | ||
| Round steel@60°(Right) | 205mm(8”) | ||
| Square steel@60°(Right) | 205x250mm(8”x9.8”) | ||
| Round steel@45°(Left ＆ Right) | 305mm(12”) | ||
| Square steel@45°(Left ＆ Right) | 305×250mm(12″×39.8″) | ||
| Saw cutting speeds | @ 50HZ | 40/80MPM | |
| @ 60HZ | 48/96MPM | ||
| Saw blade size | 27×0.9×3960mm | ||
| Motor power | 1.5/2.2KW | ||
| Drive | Gear | ||
| Package size | 250×230×163cm | ||
| NW/GW | 1250/1430kg | ||
