Product Main Technical Parameters
Band Saw Machine Main Performance Characteristics：
1. Maximum capability 9”
2. Featured in variable speed,
3. The quick clamps can be rotated from0°to 45°
4. High-capacity due controlled by motor,
5. The falling speed of saw bow is controlled by hydraulic cylinder, the base of the roller can be move freely,
6. Has a sizing device(the machine will automatically stop after sawing materials)
7. With power break protection device, machine will power off automatically when the rear protective cover is opened,
8. With coolant system, can prolong the service life of saw blade and improve the precision of work piece,
9. Equipped with a block feeder(with fixed sawing length).
10. V-belt driven, is infinitely adjustable blade speed through PIV transmission,
Band Saw Machine Application：
For high precision metal cutting, is the ideal equipment for the industrial and mining enterprises and small workshops, use is very extensive.
Band Saw Machine Main Technical Parameters:
| Model | BS-916V | ||
| Machining capacity | Round steel@90° | 229mm(9″) | |
| Square steel@90° | 127×405mm(5″×16″) | ||
| Round steel@60° | -- | ||
| Square steel@60° | -- | ||
| Round steel@45° | 150mm(6”) | ||
| Square steel@45° | 150×190mm(6″×7.5″) | ||
| Saw cutting speeds | @ 60HZ | 22-122MPM 95-402FPM | |
| @ 50HZ | 18-102MPM 78-335FPM | ||
| Saw blade size | 27×0.9×3035mm | ||
| Motor power | 1.5KW 2HP(3PH) | ||
| Drive | V-belt | ||
| Package size | 180×77×114cm | ||
| NW/GW | 300/360kg | ||
