Product Main Technical Parameters
CNC Sawing Machine Feature :
1.Extremely rigid dual-column cast-iron construction
2.PlC control for a fully automated sawing process
3.Easy to use touch sreen monitor for easy and quick recording of saw parameters
4.The feed unit's linear measuring system ensure long term maximum accuracy
5.Feed of the saw frame is infinitely variable via a hydraulic throttle valve
6.Extra rigid ,adjustable saw blade guide
7.hydraulic workpiece clamping with clamping pressure control and bundle vise are included in the standard equipment
CNC Sawing Machine Main Technical Specifications:
| Specifications | Unit | GHS-4250 | GHS-4260 |
| Cutting Capacity | mm | 500-500×500 | 600-600×600 |
| Blade size | mm | 5800x41x1.3 | 6500x41x1.3 |
| Blade speed | m/min | 27,45,69 | 27,45,69 |
| Main motor Power | kW | 5.5 | 5.5 |
| Hydraulic Motor Power | kW | 0.75 | 0.75 |
| Coolant pump motor Power | kW | 0.09 | 0.09 |
| Dimension | mm | 1860×900×1100 | 1860×900×1100 |
| Standard equipment | Optional equipment |
PlC control, 1 saw blade belt, Hydraulic workpiece clamping, Bundle vise, Material support stand, Coolant system, Work lamp,Operation manual | Automatic blade breakage control, Fast drop protection devise, Hydraulic blade tension, Automatic chip removal device, Various blade linear speed, Blade protection covers, Wheel cover opening protection, Ce standard electrical equipment |
