Product Main Technical Parameters
| Max. Load of table | 2500kg |
| Max. Allowable torque of spindle | 1100N.m |
| Max. Allowable torque of facing plate | 1100N.m |
| Max.axial feed resistance of spindle | 13000N |
| Spindle speed step | No step |
| Face plate speed step | No step |
| Spindle speed range | 12-1100r／min |
| Face plate speed range | 4-130r／min |
| Rapid feed of spindle axis | 3600mm/min |
| Rapid feed of face plate radial tool holder | 1180mm/min |
| Spindle dia. | 110mm |
| Table size (L×W) | 1320×1010mm |
| Max. distance from spindle axis to table surface | 905mm |
| Min. Distance from spindle axis to table surface | 5mm |
| Vertical travel of spindle box | 900mm |
| Spindle axial travel | 550 mm |
| Facing plate tool holder’s radial travel | 160 mm |
| Longitudinal travel of table | 1350 mm |
| Cross travel of table | 1250 mm |
| Max. Boring dia. of spindle | φ240 mm |
| Max. Maching dia. of facing head | 630 mm |
| Max. Drilling dia. | φ50 mm |
| Spindle taper | BT50 |
| Main motor power | 11／15kW |
| X、Y、W rapid feed speed | 5000mm/min |
| Overal dimension(l×w×h) | 5375×2995×3035 mm |
| Machine weight | 12300kg |
