Product Main Technical Parameters
Boring and Milling Machine Main Features and Uses：
1. Appearance beautiful generous overall layout of the overall layout.
2. The machine body, the upright post and the sliding block are all made of rectangular guide rail, and the stability is good.
3. Guide rail to take automatic quenching, high wear resistance.
4. Digital synchronous display, intuitive and accurate, can improve the work efficiency.
5. After the tailstock is optional
Boring and Milling Machine Application:
1. This machine is suitable for machining the parts of single piece or small batch production in the machine shop.
2. Drilling, boring and hinge hole can be carried out on the machine tool.
Boring and Milling Machine Optional Configuration:
Universal boring head
Face milling cutter
Tailstock
Boring bar
3 Axis DRO
Boring and Milling Machine Main Technical Specification:
| Specifications | Units | TX611 |
| Spindle bore | mm | 110 |
| Spindle taper | morse | MT6 |
| Spindle speed | r/min | 20-450(9 steps) |
| Table size (L*W) | mm | 1100×900 |
| Table longitudinal travel | mm | 1400 (Without Tailstock) |
| Table cross travel | mm | 900 |
| Spindle box travel | mm | 900 |
| Axial travel of spindle | mm | 400 |
| Table feed speed（steps） | mm/min | 6-160mm/min（6 steps）servo drive |
| Table rapid speed | mm/min | 2000 |
| Spindle box lifting speed | mm/min | 50/400 |
| Spindle motor power | kw | 5.5 |
| Weight | kg | 9000 |
| Overall dimensions | mm | 3800×2200×2560 |
