Product Main Technical Parameters
Drilling and Milling Machine Main Performance Characteristics：
1. Gear-driven type and round column
2. Milling, drilling, boring, reaming
3. Headstock swivels 360 horizontally
4. Micro feed precision
5. Adjustable gibs on table precision.
6. Strong rigidity, powerful cutting and precisely positioning.
Drilling and Milling Machine Main Technical Parameters:
| ITEM | ZAY7020G | ZAY7032G |
| Drilling capacity | 20mm | 32mm |
| Face milling capacity | 63mm | 63mm |
| End milling capacity | 20mm | 20mm |
| Distance from spindle nose to table | 439mm | 440mm |
| Min.distance from spindleaxis to column | 197.5mm | 272.5mm |
| Spindle travel | 85mm | 130mm |
| Spindle taper | M.T.3 or R8 | M.T.3 or R8 |
| Step of spindle speed | 6 | 6 |
| Range of spindle speed 50Hz | 95-1420 r.p.m | 80-1250 r.p.m |
| 60Hz | 115-1700 r.p.m | 95-1500 r.p.m |
| Swivel angle of headstock(horizontally/perpendicularly) | 360°/±90° | 360°/±90° |
| Table size | 520×160mm | 800×240mm |
| Forward and backward travel of table | 140mm | 175mm |
| Left and right travel of table | 290mm | 500mm |
| Motor power | 0.37KW | 0.75KW(1HP) |
| Net weight/gross weight | 130kg/190kg | 315kg/365kg |
| Packing size | 680×750×1000mm | 770×880×1160mm |
| Standard accessories | Optional accessories |
Allen wrench, Drift Spanner, Drill chuck rod, Screw-driver, Draw bar and gasket | Stand, Oil basin, Power feed attachment, Machine vice, Drill chuck, Milling cutter holder, Reducing sleeve, Mill chuck, Boring rod, Tapping electrical system , Coolant system |
