Product Main Technical Parameters
Drilling and Milling Machine Main Performance Characteristics：
Reinforced type gear, transmission torque large
B1 type optional 2-speed motor, spindle speed range widely.
Drilling and Milling Machine Application：
Widely used in single or batch is machinery manufacturing industry; instrument; building decoration and repair department.
Drilling and Milling Machine main technical Specifications:
| Specifications | ZX7040B/ZX7040B1 |
| Max. Drilling capacity (mm) | cast iron:40/ Steel: 32 |
| Max. face mill capacity (mm) | 80 |
| Diameter of vertical milling (mm) | 22 |
| Diameter of column(mm) | 115 |
| Spindle travel (mm) | 110 |
| Distance spindle axis to column generating line (mm) | 261.5 |
| Max. Distance spindle nose to table (mm) | 450 |
| Spindle taper | MT4 orR8 |
| Spindle speeds range (r/min) | 50～1250/50～2500 |
| Spindle speeds series | 6/12 |
| Spindle feeds(mm/r) | 0.12 0.18 0.25 |
| Dimension of worktable surface (mm) | Standard : 730x210 select: 820x240 |
| Table travel (mm) | Standard :450×170 select: 540x170 |
| Dimension of base(mm) | 605x400 |
| Overall height (mm) | 1100 |
| Main motor (W) | Single-phase：1100 Three-phase： 1500 |
| G.W/N.W(Kg) | 390/350 |
| Packing dimension (cm) | 97×77×116 |
