Product Main Technical Parameters
Radial Drilling Machine Main Performance Characteristics:
Mechanical transmission
Mechanical clamping
Mechanical change speed
Automatic tools retraction
Drill fixed depth
Radial Drilling Machine Main Technical Parameters
Specifications | Unit | Z3040x11C | Z3040x14C |
Max.drilling dia. | mm | 40 | 40 |
Distance from spindle nose to working surface of base | mm | 180-1110 | 270-1200 |
Distance from spindle axis to column generating line | mm | 350-1060 | 350-1380 |
Headstock horizontal travel | mm | 700 | 1030 |
Spindle travel | mm | 250 | 250 |
Spindle taper | MT | 4 | 4 |
Spindle speed range | rpm | 40-1250 | 40-1250 |
Spindle speed steps | 6 | 6 | |
Spindle feeding range | rpm | 0.10-0.25 | 0.10-0.25 |
Spindle feeding steps | 3 | 3 | |
Radial arm lifting travel | mm | 680 | 680 |
Radial arm lifting speed | M/min | 1.32 | 1.32 |
Max.allowable spindle torque | N.m | 300 | 300 |
Max.allowable spindle feed resistance force | N | 10000 | 10000 |
Main motor power | kw | 3 | 3 |
Weight | kg | 1500 | 2100 |
Overall dimensions | mm | 1500x705x2200 | 1800X810X2300 |
