Product Main Technical Parameters
Specifications | Z5032/1 | Z5040/1 | Z5045/1 | |
Max.drilling dia. | 32mm | 40mm | 45mm | |
Spindle taper | M.T.3 or R8 | M.T.4 | M.T.4 | |
Spindle travel | 130mm | 130mm | 130mm | |
Step of speed | 6 | 6 | 6 | |
Range of spindle speed | 50Hz | 80-1250 r.p.m | 80-1250 r.p.m | 80-1250 r.p.m |
60Hz | 95-1500 r.p.m | 95-1500 r.p.m | 95-1500 r.p.m | |
Step of spindle auto-feeding | 6 | 6 | 6 | |
Range of spindle auto-feeding amount | 0.06-0.30mm/r | 0.06-0.30mm/r | 0.06-0.30mm/r | |
Min.distance from spindle axis to column | 290mm | 290mm | 290mm | |
Max.distance from spindle nose to worktable | 725mm | 725mm | 725mm | |
Max.distance from spindle nose to stand table | 1125mm | 1125mm | 1125mm | |
Max.travel of headstock | 250mm | 250mm | 250mm | |
Swivel angle of headstock(horizontal) | 360° | 360° | 360° | |
Max.travel of worktable bracket | 600mm | 600mm | 600mm | |
Worktable size of avaliability | 380×300mm | 380×300mm | 380×300mm | |
Swivel angle of table horizontally | 360° | 360° | 360° | |
Table leaned | ±45° | ±45° | ±45° | |
Size of stand worktable of avaliability | 417×416mm | 417×416mm | 417×416mm | |
Motor power | 0.75KW(1HP) | 1.1KW(1.5HP) | 1.5KW(2HP) | |
speed of motor | 1400 r.p.m | 1400 r.p.m | 1400 r.p.m | |
Cooling pump power | 0.04KW | 0.04KW | 0.04KW | |
Net weight/Gross weight | 437kg/487kg | 442kg/492kg | 442kg/492kg | |
Packing size | 1850×750×1000mm | 1850×750×1000mm | 1850×750×1000mm |
