Product Main Technical Parameters
Specifications | Z5032 | Z5040 | Z5045 | |
Max.drilling dia. | 32mm | 40mm | 45mm | |
Spindle taper | M.T.3 or R8 | M.T.4 | M.T.4 | |
Spindle travel | 130mm | 130mm | 130mm | |
spindle speed steps | 6 | 6 | 6 | |
spindle speed range | 50Hz | 80-1250 r.p.m | 80-1250 r.p.m | 80-1250 r.p.m |
60Hz | 95-1500 r.p.m | 95-1500 r.p.m | 95-1500 r.p.m | |
Min.distance from spindle axis tocolumn | 283mm | 283mm | 283mm | |
Max.distance from spindle nose toworktable | 725mm | 725mm | 725mm | |
Max.distance from spindle nose tostand table | 1125mm | 1125mm | 1125mm | |
Max.travel of headstock | 250mm | 250mm | 250mm | |
Swivel angle of headstock (horizontal/perpendicular) | 360°/±90° | 360°/±90° | 360°/±90° | |
Max.travel of worktable bracket | 600mm | 600mm | 600mm | |
Worktable size of avaliablity | 380×300mm | 380×300mm | 380×300mm | |
Swivel angle of table horizontally | 360° | 360° | 360° | |
Table leaned | ±45° | ±45° | ±45° | |
Size of stand worktable of avaliability | 417×416mm | 417×416mm | 417×416mm | |
Motor Power | 0.75KW(1HP) | 1.1KW(1.5HP) | 1.5KW(2HP) | |
speed of motor | 1400 r.p.m | 1400 r.p.m | 1400 r.p.m | |
Net weight/Gross weight | 430kg/480kg | 432kg/482kg | 435kg/485kg | |
Packing size | 1850×750×1000mm | 1850×750×1000mm | 1850×750×1000mm |
