Product Main Technical Parameters
Specifications | Z5032C/1 | Z5040C/1 | Z5045C/1 |
Max. Drilling dia. | 32mm | 40mm | 45mm |
Spindle taper | M.T.3 or R8 | M.T.4 | M.T.4 |
Spindle travel | 130mm | 130mm | 130mm |
Step of speed | 6 | 6 | 6 |
Range of spindle speed 50Hz | 80-1250 r.p.m | 80-1250 r.p.m | 80-1250 r.p.m |
60Hz | 95-1500 r.p.m | 95-1500 r.p.m | 95-1500 r.p.m |
Step of spindle auto-feeding | 6 | 6 | 6 |
Range of spindle auto-feeding amount | 0.06-0.30mm/r | 0.06-0.30mm/r | 0.06-0.30mm/r |
Min.distance from spindle axis to column | 290mm | 290mm | 290mm |
Max.distance from spindle nose to worktable | 700mm | 700mm | 700mm |
Max.distance from spindle nose to stand table | 1125mm | 1125mm | 1125mm |
Max.travel of headstock | 250mm | 250mm | 250mm |
Swivel angle of headstock(horizontal) | 360° | 360° | 360° |
Max.travel of worktable bracket | 600mm | 600mm | 600mm |
Table Size | 730×210mm | 730×210mm | 730×210mm |
Size of stand worktable of avaliability | 417×416mm | 417×416mm | 417×416mm |
Forward and afterward travel of worktable | 205mm | 205mm | 205mm |
Left anf right travle of worktable | 500mm | 500mm | 500mm |
Vertical travel of worktable | 570mm | 570mm | 570mm |
Motor Power | 0.75kw | 1.1kw | 1.5kw |
speed of motor | 1400rpm | 1400rpm | 1400rpm |
Coolant pump power | 0.04kw | 0.04kw | 0.04kw |
Net weight/Gross weight | 437/500kg | 442/502kg | 443/505kg |
Packing size | 1850x750x1000mm | 1850x750x1000mm | 1850x750x1000mm |
