Product Model:

Z5040A Vertical Drilling Machine

Product Main Technical Parameters

ModelUnitZ5040A
Max. drilling capacityMm40
Max. tapping capacityMmM22
Distance spindle axis to column surfaceMm590
Max. distance spindle nose to baseMm1175
Max. spindle travelMm200
Spindle taper
MT4
Number of speed step of the spindleStep12
Spindle speed ranger/min52-1400
Feed steps of the spindledegree4
Feed range of the spindleMm/r0.1,0.2,0.3,0.4
Max. stroke of the worktable and its bracketMm530(410)
Rotation degree of worktable and its bracket in cross directionDegree±45°
Working area of the worktableMm580*460
Dia. of colunmm160
Main motor powerKW2.2
Max. external dimensionMm940*680*2405
N.WKg650
