Product Model:

Z5132 Vertical Drilling Machine

Product Main Technical Parameters

Vertical Drilling Machine Description:

1.This vertical drilling machine is universal type machine tool. This machine is suitable for drilling, reaming, milling, drilling, boring, tapping countersunk hole etc.. Automatic reverse feed spindle tapping and fretting, for blind and deep hole is very convenient. Widely used in machinery manufacturing, workshop production and construction processing, etc..

2.This machine tool has the advantages of high efficiency, good rigidity, high precision, low noise, wide speed range, high speed operation, novel appearance, convenient maintenance and so on.



Vertical Drilling Machine Main Technical Specifications:

SpecificationsZ5132
Max drilling dia32mm
Max feed resistance12000N
Max. spindle allowable torque200N.m
Spindle taperMorse No. 4
Distance from spindle axis to column guideway280mm
Spindle travel200mm
Spindle box travel200mm
Spindle speed50~2000r/min(9)
The amount of feed(mm/rev)0.056-1.80mm/r (9)
Working table stroke310mm
Working table surface size400×550mm
Distance from spindle nose to table surface710mm
Main motor power2.2kw
Cooling pump flow25L/min
Overall dimension980*807*2302mm
N/W1250kg
