Product Main Technical Parameters
| Specifications | unit | ZXK650 | ZXK860 | ZXK1370 |
| X/Y/Z axis stroke | mm | 600/500/550 | 850/600/600 | 1300/700/650 |
| Distance between spindle nose to worktable surface | mm | 120-670 | 180-780 | 150-800 |
| Distance between spindle to column surface | mm | 520 | 600 | 785 |
| Worktable size | mm | 800*450 | 1050*600 | 1400*710 |
| Max. load capacity | Kg | 350 | 800 | 1000 |
| T slot(number-width-pitch) | Mm | 15x15x12 | 15x15x12 | 15x15x12 |
| X/Y/Z axis fast feed | m/min | 15x15x12 | 15x15x12 | 15x15x12 |
| Spindle speed | Rpm | 8000/10000/12000/15000 | 40-3000 | 8000 |
| Spindle taper | BT40 | BT40/Φ140 | BT50 | |
| Spindle motor | Kw | 7.5HP(5.5kw) | 10HP(7.5kw) | 20HP(15kw) |
| Control system | Mitsubishi:M70A/M70B, FANUC 0I MF, Syntec 21M, KND, GSK controller | |||
| X/Y/Z positioning accuracy | mm | ±0.005/300 | ±0.005/300 | ±0.005/300 |
| Repeat positioning accuracy | mm | ±0.004/300 | ±0.004/300 | ±0.003/300 |
| Machine dimension (Length*width*height) | mm | 2200*2450*2500 | 2600*2400*2600 | 3760*2915*2700 |
| Machine Weight | Kg | 3800 | 5000 | 10500 |
