CAK6166 CNC Lathe Machine

Inquire Now Next Product

Product Main Technical Parameters

CNC Lathe Machine Features :

1.Big torque ,high precision spindle

2.Hydraulic shift ,easy operate

3.Z axis feed is directly connected which has high transmission accuracy and high positioning accuracy

4.Vertical 4 position electric toolpost with high positioning accuracy

CNC Lathe Machine Application :

CAK series CNC lathe machine is an economical ,practical type machine tools iwth good quality .

The machine has a very wide use which is suitable or internal and external turning ,tapering,circular arc ,thread ,boring ,reaming of axle and disk workpiece .It also can achieve non-circular curve machining ,You can choose the CNC system and optional accessories according to your requirement .

CNC Lathe Machine Main Technical Specifications:

SPECIFICATIONS	Units	CAK6166 CAK6166B CAK6166C
Swing over bed	mm	660
Swing over cross slide	mm	380
Distance between centers	mm	750/1000/1500/2000/3000
Spindle bore	mm	52,(80 for B),[105 for C]
Spindle bore taper	-	MT6,(φ90 1:20 for B),[φ113 1:20 for C]
Spindle nose type	-	C6,(D8 for B),[D8 for C]
Spindle speed steps	-	Manual 3 steps (Optional: stepless)
Spindle speed range	rpm	21-150,66-500,162-1500 (Optional: 100-1600 )
Turret/tool post	-	Electric 4 position
Tool size	mm	25 x 25
X axis travel	mm	330
Z axis travel	mm	750/1000/1500/2000/3000
X axis rapid traverse	mm/min	6000
Z axis rapid traverse	mm/min	10000
Tailstock quill diameter	mm	75
Tailstock quill taper	-	MT5
Tailstock quill travel	mm	150
Main spindle motor	kw	11
Coolant pump motor	kw	0.125
Weight for 750	kg	2650
Weight for 1000	kg	2750
Weight for 1500	kg	2850
Weight for 2000	kg	3350
Weight for 3000	kg	4150
Dimension for 750	mm	2550x1750x1850
Dimension for 1000	mm	2750x1750x1850
Dimension for 1500	mm	3250x1750x1850
Dimension for 2000	mm	3700x1750x1850
Dimension for 3000	mm	4710x1750x1850
