Product Main Technical Parameters
| SPECIFICATION | Units | QK1338 |
| Swing over bed | mm | 1000 |
| Swing over cross slide | mm | 610 |
| Distance between centers | mm | 1500/3000 |
| Pipe threading range | mm | 190-380 |
| Guideway width | mm | 755 |
| Max. load capacity | T | 6 |
| Spindle bore | mm | 390 |
| Spindle speed steps | - | VF. 3 steps |
| Spindle speed range | rpm | 8-205 |
| Chuck | mm | φ8504-jaw electric |
| Turret/tool post | - | |
| Tool shank size | mm | 40 x 40 |
| X axis travel | mm | 520 |
| Z axis travel | mm | 1250/2750 |
| X axis rapid traverse | mm/min | 4000 |
| Z axis rapid traverse | mm/min | 4000 |
| Tailstock quill diameter | mm | φ160 |
| Tailstock quill taper | - | MT6 |
| Tailstock quill travel | mm | 300 |
| Main spindle motor | kW | 22 |
| Coolant pump motor | kW | 0.125 |
| Weight for 1500 | kg | 12000 |
| Weight for 3000 | kg | 13000 |
| Dimension for 1500 | mm | 5000x2220x2120 |
| Dimension for 3000 | mm | 6500x2220x2120 |
