Product Main Technical Parameters
| Specifications | Units | M1320 | MW1320 | |
| Max. length ground(O.D) | mm | 500/750 | 500/750 | |
| Center height | mm | 125 | 135 | |
| Dia. Ground(O.D) | mm | 8-200 | 8-200 | |
| Max. weight of work piece kg | kg | 50 | 100 | |
| Center taper | MT | 3 | 4 | |
| Spindle speed | r/min | 50HZ:25~260 | 50HZ:25~380 Stepless | |
| Wheel size (ODxWxID) | mm | 400x40x203 | 500*50*203 | |
| Peripheral velocity | m/s | 35 | 35 | |
wheel spindle speed | r/min | 1335 | 1335 | |
| Wheel head rapid travel | mm | 50 | 50 | |
| Max. travel | mm | 205 | 205 | |
| Hand feed per rev | mm/rev | 1 | rough:2 precision：0.5 | |
| Hand feed per gra | mm/gra | 0.00125 | rough：0.01 precision：0.0025 | |
| Wheel size (ODxWxID) | mm | 500*50*203 | 500*50*203 | |
| Peripheral velocity | m/s | 35 | 35 | |
| Hand feed per | mm/rev | 6 | 6 | |
| Max. swiveling angle of table | Clockwise | ° | 5° ( 500 ) 3° ( 750 ) | 3° |
| Anticlockwise | ° | 9° | 9° (500) 8° (500) | |
| Longitudinal speed range of table | m/min | 0.1-4 | 0.1-4 | |
| Center taper | MT | 3 | 4 | |
| Quill travel mm | mm | 25 | 30 | |
| Wheelhead motor power | kw | 3 | 5.5 | |
| Workhead motor power | kw | 0.25/0.37 | 1.1 | |
| Machine weight | kg | 2400 ( 500 ) 2900 ( 750 ) | 3000(500) 3100(750) | |
| Overall dimension(L * W * H) | mm | 1920x1450x2050(500) | 2350*2030*2050(500) | |
| 213x145x205 (750) | 2750*2030*2050(750) | |||
