Product Main Technical Parameters
| Specifications | Units | M1332 | M1332A | |
| Max. length ground(O.D) | mm | 1000、1500、2000、3000 | 1000、1500、2000、3000 | |
| Center height | mm | 180 | 180 | |
| Dia. Ground(O.D) | mm | 8-320 | 8-320 | |
| Max. weight of work piece kg | kg | 150 | 500 | |
| Center taper | MT | 5 | 5 | |
| Spindle speed | r/min | 26、52、90、130、180、260 | 26、52、90、130、180、260 | |
| Wheel size (ODxWxID) | mm | 600*75*305 | 600*75*305 | |
| Peripheral velocity | m/s | 35 | 35 | |
wheel spindle speed | r/min | 1100 | 1100 | |
| Wheel head rapid travel | mm | 50 | 50 | |
| Max. travel | mm | 235 | 235 | |
| Hand feed per rev | mm/rev | rough:2 precision：0.5 | rough:2 precision：0.5 | |
| Hand feed per gra | mm/gra | rough：0.01 precision：0.0025 | rough：0.01 precision：0.0025 | |
| Wheel size (ODxWxID) | mm | 600*75*305 | 600*75*305 | |
| Peripheral velocity | m/s | 35 | 35 | |
| Hand feed per | mm/rev | 6 | 6 | |
| Max. swiveling angle of table | Cockwise | ° | 3° | 3° |
| Anticlockwise | ° | 7° (1000) 6° (1500) 5° (2000) 3° (3000) | 7° (1000) 6° (1500) 5° (2000) 3° (3000) | |
| Longitudinal speed range of table | m/min | 0.1-4 | 0.1-4 | |
| Center taper | MT | 4 | 4 | |
| Quill travel mm | mm | 30 | 30 | |
| Wheelhead motor power | kw | 11 | 11 | |
| Workhead motor power | kw | 0.85/1.5 | 1.5/2.4 | |
| Machine weight | kg | 3500(1000) 4600(1500) 7900(2000) 9900(3000) | 5300(1000) 6000(1500) 7900(2000) 9900(3000) | |
| Overall dimension(L * W * H) | mm | 3260*2000*2050(1000) | 3260*2000*2050(1000) | |
| 4260*2000*2050(1500) | 4260*2000*2050(1500) | |||
| 5400*2000*2050(2000) | 5400*2000*2050(2000) | |||
| 7390*2000*2050(3000) | 7390*2000*2050(3000) | |||
