C6241 Horizontal Lathe Machine Price

Home > Products > other products > Lathe machine

Product Model：

Inquire Now Next Product

Product Main Technical Parameters

SPECIFICATIONS	Units	C6241	C6246	C6246E
Max Swing diameter over bed	mm	410(16")	460(18")	460(18")
Max Swing diameter over cross slide	mm	220(8-13/16")	270 (10-3/4")	270(10-3/4")
Max Swing diameter over gap	mm	640(25-1/8")	690(27-1/8")	690 (27-1/8")
Gap length	mm	165(6-1/2")	165(6-1/2")	165(6-1/2")
Distance between centers	mm	1000(40") 1500(60") 2000(80")
Width of bed width	mm	300(11-13/16")
Spindle nose type	-	Dl-6		Dl-8
Spindle bore diameter	mm	58(2-1/4")		80(3-1/8")
Spindle bore taper	-	MT6		MT7
Spindle speed range	rpm	25-2000
Spindle speed steps	-	12
Top tool post travel	mm	128(5")
Cross slide travel	mm	285(11-1/4")
Tool size	mm	25*25(1" xl")
Lead screw threads	T.P.L	6mm or4TP.I.
Longitudinal feeds range	mm/r	42 kinds, 0.031-1.7(0.0011"-0.0633")
Cross feeds range	mm/r	42 kinds, 0.014-0.784(0.00033"-0.01837")
Kinds of metric threads	kinds	41
Range of metric threads	mm	0.1-14
Kinds of inch threads	kinds	60
Range of inch threads	T.P.I	2-112
Kinds of pitch threads	kinds	50
Range of pitch threads	D.P.	4-112
Kinds of module threads	kinds	34
Range of module threads	M.P.	0.1-7
Tailstock quill diameter	mm	60(2-5/16")
Tailstock quill travel	mm	130(5")
Tailstock quill taper	-	MT4
Main motor power	kw	5.5(7.5HP)
Coolant motor power	kw	0.1(l/8HP)
Weight for 1000	kg	1844	1910	1910
Weight for 1500	kg	2049	2115	2115
Weight for 2000	kg	2229	2295	2295
Weight for 3000	kg	-	-	-
Dimension for 1000	mm	225011201620	225011201620	225011201620
Dimension for 1500	mm	280011201620	280011201620	280011201620
Dimension for 2000	mm	330011201620	330011201620	330011201620
