Product Main Technical Parameters
| Model | CJM280/500 | CJM280/750 | |
| Max.swing over bed | 280 mm | ||
| Max.processing length | 500mm | 750mm | |
| Max.swing voer corss slide | 165 mm | ||
| Spindle hole | 38 mm | ||
| Spindle taper | MT.5# | ||
| Compound cross travel | 160 mm | ||
| Compound longitudinal travel | 75 mm | ||
| Metric thread kinds | 18 | ||
| Metric thread range | 0.20～3.5 mm | ||
| Inch thread kinds | 34 | ||
| Inch thread range | 41/2～48 1/n″ | ||
| Module thread kinds | 16 | ||
| Module thread range | 0.20～1.75 π | ||
| Diameter thread kinds | 24 | ||
| Diameter thread range | 16～120 π/DP″ | ||
| Longitudinal feed at spindle every turn | 0.05～0.35 mm/r | ||
| Cross feed at spindle every turn | 0.025～0.18 mm/r | ||
| Max.travel of tailstock sleeve | 60 mm | ||
| Tailstock taper | MT.3# | ||
| Spindle speed steps | 8 | ||
| Spindle speed range | 90～1800 r/mim | ||
| Main motor | 750W 380V 50HZ (or 220V 50HZ) | ||
| Net weight | 240kg | 260kg | |
| Gross weight | 300kg | 320kg | |
| Overall dimension (L*W*H) | 1200×650×1200 | 1450×650×1200 | |
| Packing size (L*W*H) | 1250×700×1300 | 1500×700×1300 | |
