Product Main Technical Parameters
Combination Lathe Milling Machine Main Performance Characteristics:
A kind of combination machines with turning, milling, drilling and threading.
Metric or imperial thread cutting
Suitable for processing metal, wood and other materials
Excellent advantage of various functions, small occupation and economization
Widely used in job-shops, car shops technical school, factories and family for machine parts repairing and making, education training, household utensils' making, etc.
HQ500V and HQ800V is with variable speed and DRO
Combination Lathe Milling Machine Main Technical Specifications:
Specifications | HQ500V | HQ800V | |
Turning | Swing over bed | φ 420mm | |
Distance between centers | 500mm | 800mm | |
Max. longitudinal travel | 440mm | 740mm | |
Max. cross travel | 195mm | ||
Taper of spindle | M. T. 4 | ||
Spindle hole | φ 28mm | ||
Step of spindle speed | Variable speed | ||
Range of spindle speed | Low:0-630rpm,High:630-1800RPM | ||
Barrel travel | 70mm | ||
Taper of center | M. T. 3 | ||
Metric thread range | 0.7-4 mm | ||
Inch thread range | 4-30T. P. I | ||
Longitudinal range of automatic feeding | 0.088-0.55mm/0.0035-0.022’’ | ||
Cross range of automatic feeding | 0.088-0.55mm/0.0035-0.022’’ | ||
Drilling and milling | Max. drilling capacity | φ 22mm | |
Worktable size (L*W) | 475× 160mm² | ||
Max. end mill | φ 28mm | ||
Max. face mill | φ 80mm | ||
Distance between spindle center and column | 285mm | ||
Distance between spindle and worktable | 306mm | ||
Headstock travel of up and down | 110mm | ||
Spindle taper | M. T. 3 | ||
Step of spindle speed | Variable speed | ||
Range of spindle speed | Low:0-800rpm,High:800-2800RPM | ||
Swivel degree of headstock | ± 360° | ||
Motor | Motor power | 0.55Kw | |
Shipping data | Packing size | 1130×580×1100mm(HQ800:1430×580×1100mm) | |
N. weight/G. weight | 245kg/280kg(HQ800:275kg/325kg) |
