Product Main Technical Parameters
| Specifications | Units | BC6085 | |
| Maximum shaping length | mm | 850 | |
| Max.range of the horizontal movement of the table | mm | 400 | |
| Max.distance between the ram bottom and table | mm | 710 | |
| Max.length of the vertical movement of table | mm | 360 | |
| Dimension of table top(L*W) | mm | 800X450 | |
| Travel of tool head | mm | 160 | |
| Number of ram strokes per minute | Times min | 17,24,35,50,70,100 | |
| Swivel of tool head | ° | +/-60 | |
| Maximum size of tool shank(W*T) | mm | - | |
| Range of table feed | Horizontal 12 steps | mm | 0.25-3 |
| vertical 12 steps | mm | 0.12-1.5 | |
| Width of the T-slot for center positioning | mm | 22 | |
| Main motor power | KW | 5.5 | |
| Overall dimension(L*W*H) | mm | 2950X1325X1693 | |
| N.w./G.W | kg | 2040/3090 | |
