Product Main Technical Parameters
Vertical Milling Machine Optional:
X travel:1000 mm
Dividing head
Rotary table
Clamping kits
DRO
Tools
Vertical Milling Machine Main Specification:
| Specifications | Units | X5036K |
| Table size | mm | 1500×360 |
| Table travel | mm | 1000/320/450 |
| T slot(number-width-pitch) | mm | 3-18-80 |
| Spindle taper | ISO50 7:24 | |
| Spindle speed range | rpm | 60-1800(12steps) |
| Distance between spindle nose and table surface | mm | 60-540 |
| Distance between spindle axis to column surface | mm | 360 |
| Main motor power | kw | 5.5 |
| Weight | kg | 3300 |
| Overall dimension | mm | 2700×2300×2400 |
