Product Main Technical Parameters
| Specifications | Units | X6128 | X6032 |
| Table size | mm | 1200×280 | 1500x320 |
| Table travel | mm | 680/280/400 | 800/300/400 |
| T slot(number-width-pitch) | mm | 5-14-50 | 3-16-70 |
| Spindle taper | IS040 7:24 | IS040 7:24 | |
| Spindle speed range | rpm | 40-1300 (12 steps) | 40-1300 (12 steps) |
| Distance between spindle axis and table surface | mm | 0-400 | 0-400 |
| Main motor power | kw | 3 | 3 |
| Weight | kg | 1300 | 2050 |
| Overall dimension | mm | 1725×1450×1750 | 2070x1900x1850 |
