Product Main Technical Parameters
Specifications | Units | X6330 |
Table size | mm | 1370x305(12”x54”) |
Table travel | mm | 810/ 400 /400 |
T slot(number-width-pitch) | mm | 3-16-65 |
Spindle taper | (V) R8/ISO40(H) ISO400 | |
Spindle speed range | rpm | (V) )50HZ:65-4500 60HZ:80-5440 (16 steps)(H) 45-1350(12steps) |
(optional)(variable)65-4000 | ||
Spindle travel | mm | 127 |
Spindle feed range | mm | 0.04,0.08,0.15(3 steps) |
Distance between spindle nose and table surface | mm | 90-510 |
Distance between spindle axis and table surface | mm | 120-520 |
Main motor power | kw | 2.2(V)3(H) |
Head rotation (left - right ) | ° | ±90° |
Head rotation (front - rear) | ° | ±45° |
Weight | kg | 1850 |
Overall dimension | mm | 1550x1650x2250 |
